Popular Pipes Group of Companies

Popular Pipes Group of Companies is a manufacturing group of companies having expertise of more than four decades. We are the pioneers and leading manufacturers of UPVC pipes and fittings.

Haji Sheikh M. Rafique started it as a cottage industry named Popular PVC Pipe Factory in 1975.

With constant dedication and firm determination of a professionally committed and skilled team working with proper planning and future forecasting, it became Popular Pipes Group of Companies.

In line with the policy of continuous demand-driven expansion, improvement in quality, diversification of products, and efficiency of operations, the organization has a nationwide distribution network with a strong presence all over Pakistan.

We have complete in-house lab facilities as per international standards where competent polymer engineers are working hard for continuous quality improvement.

With the best R&D facilities and professional workforce, we are engaged to provide the best for our valued customers.

Our organization solely represented Pakistan’s PVC Pipe Industry at Qatar Exhibition.

We were also the sole participants having the privilege of getting our name published in the “PVC 2017 world conference Brighton-UK”.

UPVC DRAINAGE SYSTEM

(Standard BS EN-1329): Unplasticized polyvinyl chloride (U-PVC) drainage Pipes & Fittings discharge inside the building structure. Unplasticized polyvinyl chloride (U-PVC) Fittings are used for non-pressure underground drainage and sewerage.

Popular Pipes produces a range of UPVC pipes for above and below-ground use made from virgin raw material. It has a full range of fittings in the solvent joint for all sizes. The pipes are produced as per standard BS EN 1329. Sizes range from 56mm to 160mm. Popular Pipes can provide a range of fittings from its own brand.

• SIZE RANGE: Pipes & Fittings: 56mm, 63mm, 82mm, 90mm, 110mm & 160mm
• COLOR: White

(Standard DIN-8062): Popular Pipes produces a range of UPVC pipes made from virgin raw material as per DIN-8062 standards.

• SIZE RANGE: Pipes & Fittings: 63mm, 90mm, 110mm & 160mm
• COLOR: White

UPVC SEWERAGE SERIES

S-60 | S-80 | S-100: Unplasticized polyvinyl chloride (U-PVC) Sewerage Series Pipes & Fittings discharge within the building structure. (Low and High Temperature) Unplasticized polyvinyl chloride (U-PVC) Fittings are used for non-pressure underground drainage and sewerage.

• SIZE RANGE: Pipes: 2?, 3?, 4?, 5?, 6? & 8?
• SIZE RANGE: Fittings: 2?, 3? & 4?
• COLOR: White

UPVC PIPES: SDR SERIES

• SIZE RANGE: 3/4? to 8? with complete Fitting range (ASTM D-2241)

UPVC PRESSURE PIPES & FITTINGS – WATER SUPPLY SYSTEM

• JOINTING: A wide range of UPVC Pipes & Fittings are available. They are economical, durable, leakproof, easy & quick to the connections. These Fittings include Coupling Sockets, Elbows, Tees, end Caps Flanges, (45 & 90), and reducers. UPVC Pipes & Fittings are available in various sizes for different pressure classes of Pipes. Confirming to BS, PS, ASTM & other international Standards.

POPULAR UPVC PRESSURE JOINTING SYSTEM

The following jointing systems are available:

1. Solvent Cement Joint
   Z Joint/Rubber Ring Joint
2. SOLVENT CEMENT JOINTING SYSTEM

PROCEDURE FOR SOLVENT JOINT INSTALLATION:

• Chamfer the Pipe at an angle of 15 or 20 to an extent of 0.5mm length
• Apply solvent cement thoroughly & evenly over the spigot end and inside of the socket
• Ensure that both spigot & socket are thoroughly clean
• Inset the pipe quickly into the socket
• Hold for a while say 4-5 minutes
• Wipe all excessive solvent cement with a cloth Leave for 24 hours before pressure testing

THINGS TO REMEMBER

• A knife or half-round coarse file, natural bristle, primer, application cane solvent cement & tools tray are required for solvent cement jointing.

Z” JOINTING SYSTEM

PROCEDURE FOR INSTALLATION:

• Ensure that the mating areas of the spigot and socket are thoroughly clean. This is extremely important for the correct positioning of the rubber ring during assembly.
• Set the rubber ring into the grove, pushing it firmly in as far as it goes all the way around. The opening in the rubber ring must face backward.
• Assess the full socket depth by simply measuring & mark the spigot accordingly. Accurate axial alignment of the spigot & socket prior to jointing is important, hand feed the spigot into the rubber joint until resistance from the inner seating section is felt.
• Stop at the entry mark (13-25mm) from the end of the socket to cater for potential expansion & contraction.
• Make sure that the pipes to be jointed are aligned correctly against each other.

U-PVC PS-1905 EQUIVALENT TO BS-6099 TERIAL

• Un-Plasticized Polyvinyl Chloride (U-PVC).
• PVC Electrical Conduits Pipe & Fittings are in Grey Color.

APPLICATIONS

• Open/surface and concealed wiring in houses, residential, commercial buildings, and industrial plants.
• Telecommunications and Cable casing application.
• Traffic signal connections, street lights & wiring at public places.

Size Range: 1/2” to 8” with complete accessories

PPR-100 PIPES AND FITTINGS

HOT & COLD WATER DISTRIBUTION SYSTEM DIN 8077/8078 DIN 16962, EN ISO 15874

• Polypropylene is the fastest-growing polymer in the pipe industry; its best quality is PPR-100 at present. PPR-100 simply means that the strength of the material is to withstand the pressure of 100 bar. That is the reason we use PPR-100 for the 1st time in Pakistan to manufacture PPR-100 pipes in three different classes PN 16, PN 20, and PN 25. PPG introduced PPR-100 fittings as per DIN 16962 and EN ISO 15874, these fittings are manufactured as per PN 25. Its metal portions are made of brass and are electroplated with food-graded nickel.

SALIENT FEATURES OF PPR-100 PIPES AND FITTINGS

• Exceptional corrosion & erosion resistance as PPR-100 is a polymer product, hence after installing PPR-100 just forget about corrosion problems & so it is an ideal product for various Chemical & other Fluids transmit applications
• High chemical resistance power even at high temperatures
• Low Thermal Conductivity makes it an ideal Piping system where one needs to Control & Maintain the Temperature. Indeed it has the lowest Thermal Conductivity compared to any other polymer
• Anti-Fungal & Non-toxic product, free from the growth of any bacteria
• Leak-proof & airtight homogeneous joints by fusion welding method
• Long Service life, above 50 years over a wide temperature range
• Negligible head loss, Minimum Pressure loss & Higher Flow Rate due to smooth internal surface & homogeneous joints
• Inherited characteristic of high impact strength makes it suitable for industrial application in unskilled labor region
• Wide Temperature range: -40C to +90C (suitable for both hot & cold applications)
• Very low thermal loss, as PPR-C is a poor conductor of heat & condensation
• Trouble-free installation process & light in weight for transmit
• Superior Impact, Fracture Resistance & Minimum Crack Transmission due to Co-polymer with random assortment.

POPULAR WATER TANK

POPULAR PVC BOARD

CABLE WIRING SYSTEM

POPULAR SOLVENT CEMENT
